Punch EV Smart

Engine Transmission

Battery Capacity: 25 kWh

Motor Power: 60 kW

Motor Type: Permanent magnet synchronous motor (PMSM)

Max Power: 80.46bhp

Max Torque: 114Nm

Range: 315 km

Battery Type: Lithium-Ion

Charging Time (A.C): 3.6H 3.3 kW (10-100%)

Charging Time (D.C): 56 Min-50 kW(10-80%)

Regenerative Braking: YES

Regenerative Braking Levels: 4

Charging Port: CCS-II

Charging Options: 3.3 kW AC Charger Box | 7.2 kW AC Fast Charger | DC Fast Charger

Charger Type: 3.3 kW AC Charger Box

Charging Time (15 A Plug Point): 9.4H (10% to 100%)

Charging Time (7.2 kW AC Fast Charger): 3.6H (10% to 100%)

Charging Time (50 kW DC Fast Charger): 56 Min (10% to 80%)

Transmission Type: Automatic

Gearbox: Single Speed

Drive Type: FWD

Fuel Performance

Fuel Type: Electric

Emission Norm Compliance: ZEV

Acceleration 0-100kmph: 13.5 s

Charging

Charging Time: 56 Min-50 kW(10-80%)

Fast Charging: YES

Suspension Steering Brakes

Front Suspension: MacPherson Strut suspension

Rear Suspension: Rear twist beam

Steering Type: Electric

Turning Radius: 4.9 m

Front Brake Type: Disc

Rear Brake Type: Drum

Dimensions Capacity

Length: 3857 mm

Width: 1742 mm

Height: 1633 mm

Boot Space: 366 Litres

Seating Capacity: 5

Ground Clearance Unladen: 190 mm

Wheel Base: 2445 mm

Front Tread: 1595 mm

No. of Doors: 5

Comfort Convenience

Power Steering: YES

Air Conditioner: YES

Heater: YES

Height Adjustable Driver Seat: YES

Ventilated Seats: NO

Electric Adjustable Seats: NO

Automatic Climate Control: YES

Air Quality Control: YES

Accessory Power Outlet: YES

Rear Reading Lamp: YES

Rear Seat Headrest: YES

Adjustable Headrest: YES

Rear Seat Centre Arm Rest: NO

Cruise Control: NO

Parking Sensors: Rear

Engine Start/Stop Button: NO

Cooled Glovebox: YES

Hands-Free Tailgate: NO

Gear Shift Indicator: NO

Rear Curtain: NO

Luggage Hook & Net: NO

Battery Saver: YES

Drive Modes: 2

Glove Box light: YES

Rear Window Sunblind: NO

Rear Windscreen Sunblind: NO

Automatic Headlamps: NO

Follow Me Home Headlamps: NO

Additional Features: Customizable Single Pedal Drive, Portable Charging Cable, ZConnect

Drive Mode Types: CITY | SPORT

Interior

Leather Wrapped Steering Wheel: NO

Leather wrap gear-shift selector: NO

Glove Box: YES

Cigarette Lighter: NO

Digital Odometer: YES

Additional Features: Smart Digital DRLs & Steering Wheel, Phygital Control panel

Upholstery: Fabric

Exterior

Headlamp Washers: NO

Rain Sensing Wiper: NO

Rear Window Wiper: NO

Rear Window Washer: NO

Rear Window Defogger: NO

Wheel Covers: YES

Alloy Wheels: NO

Tinted Glass: NO

Roof Carrier: NO

Side Stepper: NO

Integrated Antenna: YES

Chrome Grille: NO

Smoke Headlamps: NO

Projector Headlamps: NO

Cornering Foglamps: NO

Roof Rails: NO

Fog Lights: NO

Convertible Top: NO

Sunroof: NO

Boot Opening: Electronic

Heated Outside Rear View Mirror: NO

Tyre Size: 185/70 R15

Tyre Type: Low rolling resistance

Wheel Size: 15 Inch

LED DRLs: YES

LED Headlamps: YES

LED Taillights: YES

LED Fog Lamps: NO

Additional Features: Low Rolling Resistance Tires

Safety

Anti-lock Braking System (ABS): YES

Central Locking: YES

No. of Airbags: 6

Driver Airbag: YES

Passenger Airbag: YES

Side Airbag: YES

Side Airbag-Rear: NO

Day & Night Rear View Mirror: YES

Curtain Airbag: YES

Electronic Brakeforce Distribution (EBD): YES

Seat Belt Warning: YES

Door Ajar Warning: YES

Tyre Pressure Monitoring System (TPMS): YES

Electronic Stability Control (ESC): YES

Rear Camera: NO

Speed Sensing Auto Door Lock: YES

ISOFIX Child Seat Mounts: YES

Hill Descent Control: NO

Hill Assist: YES

Impact Sensing Auto Door Unlock: YES

360 View Camera: NO

Global NCAP Safety Rating: 5 Star

Entertainment Communication

Radio: NO

Integrated 2DIN Audio: NO

Wireless Phone Charging: NO

Bluetooth Connectivity: NO

Touchscreen: NO

Android Auto: NO

Apple CarPlay: NO

Usb Ports: NO

Additional Features: NO

Speakers: NO
